Optic nerve

Synonyms
Sehnerv, Optic nerve, CN II

The optic nerve is the second Cranial nerve and enables vision by transmitting the impulses generated in the retina to the Brain.

Anatomy

The optic nerve extends bilaterally from the eyeball through the Canalis opticus to the Chiasma opticum at the base of the brain[^1]. The two optic tracts emerge from the optic chiasm and run bilaterally around the cerebral peduncles to the Corpus geniculatum laterale.

Figure

Schematic optic nerve
Schematic anatomical drawing of the optic nerve. Figure adapted from Habal MB et al. 1977.

Clinical examination

Assessment of the optic nerve includes evaluation of Visual acuity, the Visual field, and the ocular fundus.

Imaging

Both the optic nerve and the optic chiasm can be visualized using MRI imaging.

Optic nerve MRI
Visualization of the optic nerve on an axial T1 MRI sequence.

Intraoperative

Intraoperatively, the optic nerve serves as an important anatomical landmark during neurosurgical procedures.

Intraoperative optic nerve
Depiction of the left optic nerve through a modified left lateral supraorbital approach (modified LSO).
